TE25 2.0

Thermal Image Scope

Image Sensor

Uncooled Focal Plane Arrays

Max. Resolution

256x192

Frame Rate

50Hz

Pixel Interval

12μm

NETD

Less than 35mK (25 °C, F#=1.0)

Response Waveband

8μm to 14μm

Lens (Focal Length)

25mm, F1.0

Detection Range

1200m

Focus Mode

Focus Ring

Min. Focusing Distance

0.5m

Magnification

3.3×-26x (8x)

Field of View(H × V), Degrees / m @100m

7.0° ×5.3°/12.3m × 9.2m

Display

1024x768, 0.39 inch, OLED

Palettes

Black Hot, White Hot, Red Hot, Fusion

FFC (Flat Field Correction) Mode

Auto, Manual, External Correction

Exit Pupil

6 mm

Eye Relief

45mm

Diopter (Range)

-5 D to 5 D

Brightness Adjustment

Yes

Tone Adjustment

Cold, Warm

Record Video

On-board Video Recording

Capture Snapshot

Yes

Standby Mode

Yes

Storage

Built-in EMMC (16 GB)

PIP

Yes

Hotspot

Yes

Hot Track

Yes

Distance Measurement

Yes

Recoil-activation Recording

Yes

Audio Recording

Yes

Max. Recoil

1000g/0.4ms

Zeroing Profiles

5

Battery Type

Replaceable and Rechargeable Li-ion Battery Pack

Battery Operating Time

≥10.5h (25 °C, with hotspot off)

Type-C Power Supply

5V DC, 2 A Supports External Power Supply

Protection Level

IP67

Dimension

218.7 mm × 67.1 mm × 68.0 mm

Weight

494g without Battery

Working Temperature

-30 °C to +55 °C (-22 °F to 131°F)
